610W Slim Line LED driver

  • Absolute Supply Voltage: 108-305Vac or 127-420Vdc, 380Vac for 2 hours
  • Horticultural Customizable Configuration
  • 95% Efficiency Max.
  • Low Inrush Current Option
  • 100,000Hour Life @ Tc=75℃
  • 7 Year Warranty @ Tc<=75℃
  • NFC Programmability and Isolated Dimming
  • +/-2% Output Current Accuracy (Programmable Model)
  • 0-10V/PWM/Time/DALI /DMX (Optional) Dimmable
  • 12V 300mA Auxiliary Power to Power Controllers and Fans
  • UL Class P, ENEC/CB/CCC SELV Output
  • Safety according to EN 61347-1, 61347-2-3, 61347-2-13, 62384

Share

This is a 610W compact constant current slim line LED driver with 95.5% high efficiency for grow lighting. The width is only 90mm, which can be installed inside the driver box.

This new 610W design covers the output current from 2.8A up to 14A. It supports very wide programming output range as a great help to reduce SKUs. At the same time, users could program the output current plus other features by NFC programmer, Cable programmer or smart cellphone. Also, it enjoys 100,000Hour Life @ Tc=75℃ and 6kV surge protection to ensure reliability. The flicker-free performance and low output current ripple < 5% provide users steady light output and a comfortable environment. Regarding the UL new requirements implemented last Nov, isolated dimming is also included in this 800W design. As usual, it still supports multiple dimming protocols and dim to off. Constant lumen output, low inrush current and NTC thermal feedback are also optional.

Product Models

Model Number Input Voltage Output Power Output Voltage Output Current Min Output Current Max Certification
BLD-610-C14A-XYZ 100-305Vac 610 W 30-55Vdc 11A 14A UL/FCC
BLD-610-C860-XYZ 100-305Vac 610 W 42-100Vdc 6A 8.6A UL/FCC
BLD-610-C600-XYZ 100-305Vac 610 W 60-143Vdc 4.2A 6A UL/FCC
BLD-610-C420-XYZ 100-305Vac 610 W 86-214Vdc 2.8A 4.2A UL/FCC
