Horticulture Lighting LED Drivers

Hot Selling Grow Lighting Drivers

horticulture lighting

Product Features

  • Absolute Supply Voltage: 200-528Vac or 250-740Vdc
  • Great Surge Immunity 10kV
  • 96% Efficiency Max.
  • Customized Endcap
  • Low Inrush Current
  • Active Daisy Chain and Master Mode
  • 100,000Hour Life @ Tc=75℃
  • 7 Year Warranty @ Tc<=75℃
  • AirsetTM NFC Programmability
  • +/-2% Output Current Accuracy
  • Isolated 0-10V/PWM/Time/DALI2.0 Dimmable
  • Dim Off with 1.5W Standby Power
  • 12V 300mA Auxiliary Power to Power Controllers and Fans (Optional)
  • UL Class P, ENEC/CB/CCC SELV Output
  • Global Certified Model Available
  • Safety according to EN 61347-1, 61347-2-13, 62384

120-277Vac Input Horticulture Lighting LED Drivers

800w 2

Square Shape

Model NumberOutput PowerOutput CurrentOutput Voltage
BLD-600-C14A-XYZ600W11-14A30-55Vdc
BLD-700-C16A-XYZ700W12.5-16A30-56Vdc
BLD-800-C18A-XYZ800W14.5-18A30-56Vdc
BLD-900-C18A-XYZ900W16.5-18A30-55Vdc
tld 400 c 4

Slim Line

Model NumberOutput PowerOutput CurrentOutput Voltage
BLD-320-C700-XYZ320W5-7A27-64Vdc
BLD-400-C990-XYZ400W6.9-9.9A24-58Vdc
BLD-500-C11A-XYZ500W9.1.1A27-56Vdc
BLD-610-C14A-XYZ610W11-14A30-55Vdc
BLD-710-C16A-XYZ710W12.5-16A30-55Vdc
BLD-810-C18A-XYZ810W14.5-18A30-56Vdc
BLD-1K1-C21A-XYZ1000W18-21A30-55Vdc

200-480Vac Input Horticulture Lighting LED Drivers

800w 2

Square Shape

Model NumberOutput PowerOutput CurrentOutput Voltage
TLD-600-C14A-XYZ600W11-14A30-55Vdc
TLD-700-C16A-XYZ700W12.5-16A30-56Vdc
TLD-800-C18A-XYZ800W14.5-18A30-56Vdc
tld 400 c 4

Slim Line

Model NumberOutput PowerOutput CurrentOutput Voltage
TLD-320-C700-XYZ320W5-7A27-64Vdc
TLD-400-C990-XYZ400W6.9-9.9A24-58Vdc
TLD-480-C11A-XYZ480W9-1.1A26-54Vdc
TLD-610-C14A-XYZ610W11-14A30-55Vdc
TLD-710-C16A-XYZ710W12.5-16A30-56Vdc
TLD-810-C18A-XYZ810W14.5-18A30-56Vdc

How to choose right LED drivers for grow lighting?

There are several factors needs to be considered when choosing suitable LED drivers for horticulture lighting

  • Choose the right power for the light fixtures.
  • Choose the right input voltage for light fixtures.
  • Higher efficiency drivers result in higher light efficacy and longer life.
  • Choose Single high power driver. Higher efficiency, Simplicity of internal wiring during manufacturing, Doubling or tripling the failure rates, Low inrush current.

LED Driver Solutions for Horticulture Lighting

Upowertek unique product features could help grow lights manufacturers win more customers.

  • Upowertek provides 2 versions input voltages: 120-277Vac and 200-480Vac, and this full range covers most of the power grids in the world.
  • The efficiency is extremely high up to 95.5%. The high efficiency results in the high light efficacy of the grow lights thus saves a lot of money for end customers.
  • Extremely low inrush current. The standard version of 400-800W driver has only less than 20A so as to ease the selection of circuit breakers for existing systems.
  • Great dimming performance. Dimmed down to 10% smoothly without any flickering.
  • Full range and choices of output. Output power ranges from 100Watt to 800Watt.
  • Ground cable at the output which makes the usage safer, and it is certified by UL Class P.
  • High Reliability and long life time up to 100khours.
grow lighting canabis
bld 610 710 810 output 800 800 led driver 450x450 1

Miscellaneous Choices

Upowertek provides full options for different grow light connections and control schemes.

Options for ConnectionIndustrial Choices IP66Consumer Choices IP20
InputCable
Waterproof Connector
C14 Plug
OutputCable
Waterproof Connector
Dimming ControlCable
Waterproof Connector
RJ12 x 2
Knob

Lead Time

  • Samples:  2 or 3 days usually. It takes more time if there is any customization requirement, such as private label.
  • Volume orders: 3 to 4 weeks usually.
  • Shipping time: It takes about 3 to 5 days to ship by express,such as DHL or UPS,  and it’s around 2 to 4 weeks by Sea.
  • Guarantee: Upowertek has an efficient team to process your orders, we try everything to short the lead time. Even under shortage of raw materials this year, we stocked enough components to meet our customer’s demand for lead time. For some top urgent projects, we have special team to ensure everything is on schedule.
warranty

7 to 10 Year Warranty

  • Upowertek has strong R&D team, strict process and professional factory to ensure high quality of the LED drivers.
  • Experienced Engineers
  • Strict Process
  • Qualified Components
  • Adequate Design Margin
  • Strict Verification Hardware System

Tell us your requirements

uPowerTek has a flexible sales strategy on grow light market, and we also would like to listen to our customer’s suggestions to optimize our products. A strong R&D team is ready to turn your idea into real products.



    *We respect your confidentiality and all information is protected

    Meet Our Team

    A professional team is always ready to deal with your requirements! The company’s core team is a group of senior engineers who have been deeply involved in the lighting and switching power supply industry for many years.
